ASME B16.11 / BS 3799· Forged Branch Fittings
High-Pressure Forged Steel Socket Weld & Screwed Fittings
Chemical injection lines, auxiliary steam piping, pressure gauge connections, and lube oil loops.
100% Stamped Heat Number Traceability
EN 10204 3.1 MTC Supplied
Air Cargo Eligible (24–48h Dispatch)
Technical specifications & verification parameters
| Parameter | Specification value |
|---|---|
| Design & manufacturing standard | ASME B16.11 / BS 3799 |
| Product classification | Forged Branch Fittings |
| Material or metallurgy grade | ASTM A105 Forged Carbon Steel / ASTM A182 F316 |
| Nominal size / dimension range | 1/4" to 4" NB (Couplings, Elbows, Tees, Hex Nipples) |
| Class or pressure rating | Class 3000 / 6000# (NPT Threaded / Socket Weld) |
| Export HS Code | 73079200 |
| Country of origin | India |
| Dispatch & lead time | Dispatch from supplier stock, confirmed at quotation · Direct sea container transit (3–4 days to UAE/Oman) or priority Air Cargo dispatch (24–48h) for emergency shutdown spares. |
| Inspection & test documentation |
|
Need dual-certification, cut-to-length studs, or CIF pricing for your project?
Pipeline flanges & buttweld fitting scope
ASME B16.5 forged flanges, ASME B16.9 buttweld seamless elbows and tees, and ASME B16.11 high-pressure socket-weld fittings for refinery headers, process piping, and water transmission pipelines.
Flange Geometries & Classes
Weld Neck (WNRF), Slip-On (SORF), Blind (BLRF), and Socket Weld flanges in ASME Class 150, 300, 600, 900, and 1500# ratings from 1/2" to 24" nominal bore.
Buttweld Fitting Geometries
Long radius 90° and 45° elbows, equal and reducing tees, concentric and eccentric reducers, and pipe caps conforming to ASME B16.9 and MSS-SP-75.
Materials & Wall Schedules
ASTM A105, ASTM A350 LF2 (low temp), ASTM A182 F316/316L, and WPB carbon steel. Wall thicknesses: Schedule 20, 40, STD, 80, XS, 160, and XXS with machined weld bevels.
Verification & MTCs
EN 10204 3.1 MTCs with stamped heat numbers, ultrasonic wall thickness inspection, dimensional verification, and Positive Material Identification (PMI) spectral analysis.
